KOPPACE 20X-200X Electron Microscope 4K HD Camera Take Pictures and Measure Continuous Zoom Lens 6 Inch Mobile Platform

KP-N1200
Camera Features:
◆ Built-in new developed version of V3 measurement system,once again improve the image definition;
◆ 4K output image,real-time frame rate 60FPS;
◆ New: custom interface editing,custom template editing,Dxf import template,file management,
measurement data export and other functions;
◆ SONY high-performance photosensitive chiplow noise,high sensitivity,real color;
◆ Dual-core 2*A73@1.6GHz+2*A53@1.2GHz;In pieces 4gb DDR4 + 8gb eMMC;
◆ Equipped with USB3.0,gigabit network interface;
◆ High-definition shooting, video recording,preview and playback;
◆ Built-in automatic edge finding function,improve the measurement effect;
◆ Support U disk storage function,can be connected to the mouse;
Have a question?
Price:
USD
$2950.99
$3699.99
    Please select the information you wantX
Quantity:
-
+
(500 available)
Shipping Cost:
to
Estimated Delivery Time:
Please select the country you want to ship from
Inquiry Now
Add to Favorite Items
  • Description
  • Reviews
Camera Features:
◆ Built-in new developed version of V3 measurement system,once again improve the image definition;
◆ 4K output image,real-time frame rate 60FPS;
◆ New: custom interface editing,custom template editing,Dxf import template,file management,measurement data export and other functions;
◆ SONY high-performance photosensitive chiplow noise,high sensitivity,real color;
◆ Dual-core 2*A73@1.6GHz+2*A53@1.2GHz;In pieces 4gb DDR4 + 8gb eMMC;
◆ Equipped with USB3.0,gigabit network interface;
◆ High-definition shooting, video recording,preview and playback;
◆ Built-in automatic edge finding function,improve the measurement effect;
◆ Support U disk storage function,can be connected to the mouse;
Point spacing,point line spacing,line spacing,center distance,arc,circle,Angle, rectangle,polygon measurement, calibration function,automatic edge searching
Model KP-N1200
Optical Enlargement 20X-200X
Zoom lens 0.7X-5X Continuously Adjustable
Optical Ratio 0.28X-2.8X
Working Distance 100mm-105mm
Focusing bracket Focusing handwheel tightness is adjustable,lifting range 50mm
Pillar aperture 32mm
Column length 500mm
Lens aperture 50mm
Base Plate size 400X300X8.6mm
Mobile Platform 6-inch large platform,Stroke 120*90mm,Size:355*230mm,Base light Source 50mm-110mm Diameter Card Slot.Glass Size:200*180mm
LED light Source LED Qty 144,Internal diameter size 59mm,Input voltage AC90,240V,Maximum output power 4.5W,Voltage 12V0.5A
Interface HDMI
Resolution 3840X2160,7680 X4320
Camera and video resolution 3840 x 2160
Like yuan size 2.0μm x 2.0μm
Target Surface size 1/1.8
Data bits 12bit
Exposure method Line by line exposure
Output frame rate 60FPS
Output color Color
Note:
1、This product is an HDMI output and can only be connected to a display with an HDMI connector.The product has two USB outputs,one for connecting a mouse and one for connecting to a USB flash drive. Measurements can be performed directly on the display with the mouse. Save pictures and Excel data.
2、This product does not contain a monitor.
3、This product is a 4K high-definition display, and it must be equipped with a 4K high-definition display to achieve the best results.
Packing List :
1、0.7X-4.5X zoom lens *1 (with magnification lock function)
2、LED light Source *1
3、6 Inches Mobile Platform *1
4、500mm long Columns *1
5、400*300mm Bottom Plate *1
6、Focusing Frame *1
7、8.3 Million pixel 4K Microscope Camera *1
8、HDMI HD Cable *1
9、Camera Power Adapter *1
10、Calibration Scale *1

**************************************************************************************************************************************************************************
